Step angle 30 degrees, 0-11 switch positions, digital multi-position rotary switch. Available types: 01N rotary band switch, 02N rotary band switch, 03N rotary band switch, 04N rotary band switch, 00N rotary band switch. We provide many output coding types: point-to-point, binary, anti-binary, gray code, and anti-gray code. There are self-tapping screws (pins) to set the working range of needs. Users can change the starting position, ending position and output code according to the code and truth table and the switch position code and signal table in the accessory. The YLDP selector rotary switch N series can customize the position range according to requirements. Adjustable rotary switch has the advantage of saving I/O points in PLC applications, and reduce the stock of inventory specifications, achieve cost-saving.
YLDP digital code switch N series is in a high-strength design that is especially suitable for on-site use. Gold-plated double contacts, stable contact resistance, prevent false signal output, and avoid misoperation. The rotary switch has a strong and durable metal appearance. The number of segments is clear and no wear. The front side sealed structure is oil-resistant and waterproof. It has protect mechanism with static resistance ±8KV and withstand voltage DC250V/50mΩ. The band selector rotary switch has high performance, and the service life exceeds 50,000 times.
