CNC Grinder MPG Pendant Handwheel

Various types of axis and multiplier switch configuration: ATOMS P7 handy MPG pendant series
Appearance
The body case is generous, and it can integrate many functions into one. The P7 handheld MPG pendant is highly customized and can apply to all CNC machines. Such as lathes, milling machines, grinders, CNC grinders, or printing machinery. Powerful magnetic back case and special MPG holder bracket can use, which is easy to control mechanical equipment in different positions.

Customization
The P7 handwheel MPG pendant series is specially designed for customer needs. It can install up to five selector switches and supports multiple codings: point-to-point, binary, and gray code. The axis selection can be set to 3, 4, 5, 6 and 7 axes, and the multiplication selection can be set to X1, X10, X100, X1000. Customized special modules can also configure with two selector switches and six function buttons for application.

Performance
The case material is robust and impact-resistant, which can prevent improper throwing and easy damage. It is suitable for factory environment and on-site operation. The P7 handy MPG series has high compatibility and can use with various controllers like MITSUBISHI, FANUC and SIEMENS. We provide related MPG spiral cable and joint welding services. It is easy to operate and install on electrical cabinets or machine tools.

The MIT high-quality rotary encoder has a circuit protection mechanism. The manual pulse generator series can withstand input voltages from DC5V to DC12V. It also has anti-electromagnetic interference, and anti-reverse voltage protection. The optional EMG emergency stop switch to ensure safe disconnection. The MPG metal dial has good texture, with indicator lights at the center point. The scale numbers on MPG are clear, does not wear or fade over time, quick output response without any signal lost. The components can replace separately, reduce maintenance time and costs.

Optional: emergency stop switch (fixed on the top of the case), enable switch (available on left side or both sides), square function buttons can choose to have indicator light or not. Additional functions freely defined by users, the pushbutton can print and placed the clear film.  We offer unique design and manufacturing, ODM and OEM services. The name plate and MPG dial can print or laser with LOGO text and full-color icons.

ATOMS P7 series configuration reference
ATOMS P7 series configuration reference
The ATOMS P7 handy MPG series is mainly designed for multiple configuration. The MPG specification, selector switch, pushbutton, emergency stop, enable switch (starter switch) and other components of the handy MPG pendant can be customized according to needs. No matter what kinds of requirement, such as a compatible MPG replacement, whole new MPG specification... we can provide reliable and valuable applications.

The minimum order quantity for the customized product is 10 pieces. For more information, please contact us.
FEATURES
  • Multi-axis selection setting, dedicated to the use of band switches above 8 bands.
  • Impact-resistant material case to extends the product service life.
  • DC5V to 24V full voltage input, anti-reverse voltage protection and electrostatic discharge ±10KV design.
  • Built-in permanent magnet to secure the handy MPG in the included bracket, for flexibly use.
  • Standard with 3-meter PU spring wire and power indicator light.
  • Coding type: binary coding, anti-binary coding, Gray coding, anti-Gray coding and point-to-point.
  • Metal MPG handwheel dial, the scale numbers are clear and easy to read.
  • Optional: emergency stop switch, enable switch(starter switch).


Related Products

Standard CNC MPG Pendant Handwheel

The ATOMS P5 series of handheld MPG pendant has IP67 and CE certified. The default configuration is four-axis (OFF-X-Y-Z-4), X1, X10, and X100 three multipliers. The P5 handwheel MPG pendant meets the needs of 4-axis machine tools, with PLC, FANUC, MITSUBISHI, SIEMENS or other controllers, which is available from stock. There are two selector switches (axis, multiplier selection) that can adjust by the user. The position of the emergency stop and start switch is reserved, which can add on demand. Customized production, lightweight, durable, with magnetic back case and optional MPG holder bracket. We can offer more diverse choices and more complete applications. Applications: automation equipment such as lathes, grinders, and special machines.

Module Function MPG CNC Pendant Handwheel

The ATOMS P9 series of handheld MPG pendant is based on a high-mix low-volume manufacturing. The P9 handwheel MPG pendant can freely configure with up to six rotary switches, nine button switches, a special round button, and optional emergency stop switch, enable switch and other customizations. Highly customized includes: selector switches, function buttons, indicator light, emergency stop, enable switch, MPG specification, and spiral coil cable. We provide customers with more diverse choices and more precise operating applications to meet various use of special CNC machines and machine tools. Applications: MITSUBISHI, FANUC, SIEMENS, HEIDENHAIN, LNC, and PC-BASE systems.

Customized MPG CNC Pendant Handwheel

The ATOMS J1 series of handheld MPG pendant has IP67 and CE certified. The design of J1 handy MPG is lightweight with reliable performance. It can customize with MPG specification, spiral coil cable, indicator light, function buttons and selector switches. The name plate can install two rotary switches, three button switches, and print company LOGO or icons. There is an emergency stop switch and enable switch can set for the requirement. It has a permanent magnet on the backside and an optional MPG holder bracket. We provide many specifications such as the cable wire conductors and connectors (male, female side), with more diverse options and more complete applications. Applications: MITSUBISHI, FANUC, SIEMENS, YASKAWA, and other CNC systems.

Digital Display CNC MPG Pendant Handwheel

The YLND series is a separate handheld MPG pendant with a numerical display. The YLND handwheel MPG pendant is mainly designed for special customization according to the needs. The screen displays the coordinate value, which is convenient for the operator to calibrate the workpiece and set the workpiece coordinate. The default configuration is one emergency stop switch and two enable switches. It has a magnetic back case and an optional MPG holder bracket. We provide many specifications such as the cable wire conductors and connectors (male, female side), no matter what kinds of requirement, we can provide reliable and valuable applications. Applications: CNC equipment such as large lathes, machine tools, industrial machines, and other special machines.

Single Axis Motion Controller MPG CNC Pendant Handwheel

The ATOMS P3 series of handheld MPG pendant is small and less occupying working space. They are compact, reliable performance. The P3 handwheel MPG pendant is mainly designed to streamline. There are two selector switches for custom settings. The MPG dial can laser or print the company LOGO or patterns. The P3 handy MPG reserves position for one emergency stop switch and two enable switches. It has a magnetic back case and an optional MPG holder bracket. We provide many specifications such as the cable wire conductors and connectors (male, female side), with more diverse options and more complete applications. Applications: MITSUBISHI, FANUC, SIEMENS, FAGOR and other CNC systems.
